Blinking Sail windmill

**US patents 7780416 & 8702393**

**Power output calculation, when the radius of the frame is 40m and height 60m.**

**20.6MW**

With a Sail 99.99% Air, 100 times lighter than Styrofoam the blinking sail
windmill can be named blinking
Dandelion windmill.

Since the sails are
as light as air therefore the lightest breeze will blow three sails away
easily.

And always we are
left with an active frame blocking the wind and generating electricity.

Sails known for
thousands of years to move huge ships, so blinking sail windmill will move huge
generator and generate electricity all the time even with the slowest wind.
Having the safety mechanism it will be safe and generating electricity in the
strongest winds ever.

The blinking sail windmill
joined with Boeing’s
microluttice will make a windmill will change the history of power
generation.

#
US patent: 21MW. First time in history sail
windmill let wind pass through but extract all its energy

https://www.youtube.com/watch?v=XhY9GxsQ2i0&feature=youtu.be

https://www.youtube.com/watch?v=XhY9GxsQ2i0&feature=youtu.be

# Short video

Boeing microluttice Makes the most powerful windmill ENDs oil coal era**https://www.youtube.com/watch?v=v05qTjXccjA&feature=youtu.be**

# Long video

# Boeing’s revolutionary microluttice lighter than Dandelion

https://www.youtube.com/watch?v=yDA0V3L8f0U#t=520# US patent 7780416 blinking sail windmill gentle wind

# US patent 7780416 blinking sail windmill fast wind

##
Moving
parts and maintenance

The only moving parts in the blinking sail windmill are the swinging windows and the sails.

The swinging windows do not move all the time; they simply swing in high
winds only. Since swinging windows are made from metal so they will last for a
hundred years. Since they move in just a quarter turn only and in high winds
only so their ballbearing will last minimum for hundred years. So the swinging
windows will not need maintenance for hundred years.

So we left with the movement of the sails of quarter turn per cycle. The
ballbearing will last minimum for 50 years since the ballbearings are currying
negligible weight. When we make the sails from long lasting materials like
Grafeen or “Carbon Fiber-Reinforced Polymer” or Carbyne, The sail will last for
tens of years with no need for maintenance.

So the blinking sail windmill practically shot and forget. Install it and
forget the maintenance for 50 years.

Noise

The sails of the BSW won't bang against the green swinging windows, not only
because the sails are extremely rigid but also because the spiral springs
attached to ball bearing of the sails will prevent the sails from banging
against the green swinging windows. They are always a distance of 10cm away
from the green swinging windows because when it returns the spiral spring will
keep the sail at 10 °degree angle from the vertical plane.

When a powerful wind push the sail it will slowly move until it touches the
green swinging window with no noise. When that happens the sail will start to
push the green swinging window out of plane to let some of the air pass
through. As the wind gets stronger and stronger the gap to let the air pass
through will get bigger and bigger; the stronger the wind the larger the gap.

The BSW's built-in safety mechanism is designed so that it can work when
wind speed is strong or super strong. The green swinging windows are fitted
with spiral Springs. When the wind is weak the green swinging windows are in
vertical position but as the wind gets stronger and stronger and the sails
start to push the green swinging windows the increased force will push the
spiral springs. This will cause the green swinging windows to shift out of
plane and consequently permit some of the air to pass freely through the slowly
widening gap. As the wind gets stronger the gap will get wider allowing more
air to pass through it. The BSW will produce power in slow and fast wind,
without making noise.

Birds

the bird can see the Blinking sail windmill clearly since it has wide
surface area and its speed is not so fast so no bird deaths will take place
like present windmills do since the tip of the blade is moving at 300km per
hour and it is invisible due to small surface aria at the tip of the blade.

Helical
BSW

Although the animations show “linear” frames, in fact when the BSWs are
built and deployed in commercial wind farms their frames will be helical. So,
how are the frames arranged and how do they look like as their numbers change?

In a BSW with 4 frames, each frame starts at a point at the bottom on the Central
Post and end at the top of the Central Post at 90 degree angle, while in a BSW
with three frames, each frame starts at a point at the bottom on the Central
Post and end at top of the Central Post at 120 degree angle. Finally, each
frame of a BSW with two frames will start at a point at the bottom of the Central
Post and end at the top of the Central Post at 180 degrees angle.

Helically-shaped frames are more aerodynamic, evenly spread the torque
experienced by the frames as they spin and will prevent pulsations. When the
blinking sail windmill becomes helical the columns will spread creating gaps
between them, where the wind pushing the sails will have an aerodynamic
passageway where wind current move dynamically in the system of blinking sail
windmill.

A powerful windmill made from the lightest
material in the world manufactured by Boeing a revelatory microluttice lighter
than Dandelion.

## Easily assembled and deployable.

## It generates electricity even at extreme low wind.

## The sails of the blinking sail windmill are so light since they are made from microluttice which is lighter than Dandelion. So the lowest wind will blow them away so the wind will pass freely from three frames while the active frame blocks the wind so we have a 20 meter by 20 meter sale blocking the wind and generating huge energy.

## A wind farm made from this blinking sail windmill which cost $100 million it will generate electricity more than a wind farm cost $10 billion made from present windmills.

## The blinking sail windmill will change the landscape of wind energy.

## HRL Researchers Develop World's Lightest Material

## http://www.hrl.com/hrlDocs/pressreleases/2011/prsRls_111117.html

# Boeing: Lightest. Metal. Ever.

## https://www.youtube.com/watch?v=k6N_4jGJADY

## https://www.youtube.com/watch?v=rWEzq8m9KHQ

Industrial
design windmill with Boeing’s revolutionary
microluttice lighter than Dandelion. Makes the most powerful windmill in
history. For Wind farms very low cost easy to
assemble by unskilled workers.

https://www.youtube.com/watch?v=yDA0V3L8f0U#t=520

## http://www.youtube.com/watch?v=LNXTm7aHvWc

**My US patents 7780416 & 8702393 windmills the energy it generates is tens of times more than the present windmill for a windmill which costs tenth the cost of the present windmill.**

**Therefore this windmill is hundreds of times more efficient than the present windmill per cost/power generated**

**The blinking sail windmill generates so much electricity due to its large size let’s say the 20 meters by 20 meters that the owner will get his money back in 142 days and that will never happen in any windmill even when they dream of one, the owner of the blinking sail windmill will get his money back in 142 days when he use it to generate electricity or make distilled water in desert countries or when making hydrogen from water to use it in cars instead of using petrol.**

**My windmill has all these three properties it cost 10% only of the cost of the present windmill and this low cost BLINKING SAIL WINDMILL generates ten time more electricity than the present windmill therefore it is 10 x 10 = 100 times more efficient than the present windmill, in view of the cost. Besides that it has much less maintenance cost since the generator is not 170 meters above the ground like the present windmill because the blinking sail windmill generator is few meters above the ground .**

therefore no lightening can damage the generator of the blinking sail windmill

.

.

**More energy is used to produce**

**present**wind turbine than it will ever generate**Blinking sail windmill only uses 14.8 tons of steel. All of it can be packed in one single track and assembled by unskilled workers without the use of any crane. It cost %1 of the cost of the present windmill.**

**Building Blinking sail windmill using tower crane**

**We can use present tower crane to make the one megawatt, 1MW blinking sail windmill, simply we fix four arms of the tower crane at the top instead of one. Where we hang on each arm of the tower crane a frame 25m width by 33m height.**

**From the photos below we can see how strong is the tower crane and it can carry the four frames of blinking sail windmill so easily as if it is carrying a father.**

**As we see the crane price can be as low as $22,000 where the four frames will cost less than $15,000**

**So with less than $40,000 we will have a 1MW windmill, if we add the generator price and the foundation cost the entire blinking sail windmill cost will be less than $175,000. With such price the blinking sail windmill will land slide the world of wind power generation.**

Links to tower crane

https://www.youtube.com/watch?v=RB91Sm-kGJ8

The life time of a ballbearing is 500000000 revelations to one million revelation.

The BSW spins between 40-100 rev per minute. Thus, taking the higher figure of turns:

BSW turn/year = 100 x 60 x 24 x 365 = 52,560,000

500000000 ÷ 52560000 = 9.61

The sails of the BSW won't bang against the green swinging windows, not only because the sails are extremely rigid but also because the spiral springs attached to ball bearing will prevent the sails from banging against the green swinging windows. They are always a distance of 10cm away from the green swinging windows because when it returns the spiral spring will keep the sail at 10 °degree angle from the vertical plane.

The BSW's built-in safety mechanism is designed so that it can work in when wind speed is weak or super strong. Thus, a powerful wind will slowly push the sail until it touches the green swinging window so no noise is resulted. When that happens it will start to push the green swinging window out of plane to let some of the air pass through. As the wind gets stronger and stronger the gap to let the air pass through will get bigger and bigger; the stronger the wind the larger the gap.

The green swinging windows too are fitted with spiral Springs. When the wind is weak the green swinging windows are in vertical position but as the wind gets stronger and stronger and the sails start to push the green swinging windows the increased force will push the spiral springs. This will cause the green swinging windows to shift out of plane and consequently permit some of the air to pass freely through the slowly widening gap. As the wind gets stronger the gap will get wider allowing more air to pass through it. The BSW will produce power in slow and fast wind, without making noise.

Given the two salient characteristics of the BSW, massive size and slow motion, it is unfathomable that this turbine will result in killing birds

The life time of a ballbearing is 500000000 revelations to one million revelation.

The BSW spins between 40-100 rev per minute. Thus, taking the higher figure of turns:

BSW turn/year = 100 x 60 x 24 x 365 = 52,560,000

500000000 ÷ 52560000 = 9.61

Since the blinking sail windmill two sail ballbearing is
caring very light weight and running at very low speed it will last minimum 20
to 30 years. The same applies to the green swinging window ballbearing.

But Since the sail ballbearing only turns 90 degree only
that means quarter turn therefore it will last: years

9.61

x

4

=

38.44 years

9.61

x

4

=

38.44 years

Where the green swinging window only move in strong wind so
the ballbearing will last much longer than 38.44 years

Let me now address the concern about noise. The sails of the BSW won't bang against the green swinging windows, not only because the sails are extremely rigid but also because the spiral springs attached to ball bearing will prevent the sails from banging against the green swinging windows. They are always a distance of 10cm away from the green swinging windows because when it returns the spiral spring will keep the sail at 10 °degree angle from the vertical plane.

The BSW's built-in safety mechanism is designed so that it can work in when wind speed is weak or super strong. Thus, a powerful wind will slowly push the sail until it touches the green swinging window so no noise is resulted. When that happens it will start to push the green swinging window out of plane to let some of the air pass through. As the wind gets stronger and stronger the gap to let the air pass through will get bigger and bigger; the stronger the wind the larger the gap.

The green swinging windows too are fitted with spiral Springs. When the wind is weak the green swinging windows are in vertical position but as the wind gets stronger and stronger and the sails start to push the green swinging windows the increased force will push the spiral springs. This will cause the green swinging windows to shift out of plane and consequently permit some of the air to pass freely through the slowly widening gap. As the wind gets stronger the gap will get wider allowing more air to pass through it. The BSW will produce power in slow and fast wind, without making noise.

Given the two salient characteristics of the BSW, massive size and slow motion, it is unfathomable that this turbine will result in killing birds

**“BSW Power Output Calculations”**

**Wind speed 10m/s**

**When we consider a BSW with 30m x 30m frame fixed at the end of a 60m arm. Then the**

**Total Power =**

**(26.9MW)**

Using the universally accepted and
used formula to calculate power output by wind turbines:

Power output (P) = 0.5 x air density at sea level (1.23) x swept area x wind
velocity cubed.

P = 0.5 × 1.23 × 2RH × V

^{3 }where:
P = Power output

0.5= The efficiency rating assigned
to the majority of wind turbines

R= In a classic wind turbine, with
three horizontally spinning rotors, R is the radius of the spinning rotor

In the case of the BSW, however, R
is the radius of the active frame denoting the distance between the frame’s
vertical column and the BSW’s Central Post.

H: In a classic wind turbine, with
three horizontally spinning rotors, H is the

**of the spinning rotor***length*
In the case of the BSW, however, H
is the height of the vertical column of the active frame.

V

^{3 }= Wind velocity (cubed) in meters per seconds.
But before I outline the power
output calculations in some detail, and in order to understand and appreciate
how these calculations are achieved, it is absolutely critical to highlight an
important feature of the structure of the BSW’s frame which plays an important
role how power is generated and calculated:

“A BSW may have 4 frames (or 5 or 6) designed to
spin and block the wind to generate electricity. Think of the BSW frame as an
Excel sheet consisting of multiple

**The columns will be juxta positioned next to each other; a series of columns, as if they are stitched together. BSWs of different sizes will have different number of columns. The larger the BSW the larger number of columns.***columns.*
The frame of a 10m x10m BSW has 5 columns, each
10m long; a frame of a 20m x 20m has 10 columns, each 20m long, while a 30m x 30m
frame will have 15 columns, each 30m long.

Just like an Excel Sheet with multiple cells,
each column has multiple number of component units called Double Sided Units. A
Double Sided Units (DSU) is 2m wide and 1m long. Different size BSWs will have
different number of DSUs. For example, a BSW with 10m x 10m frame will have 200
DSU; a 20m x 20m frame will have 800 DSU while a 30m x 40m will have 2400 DSU”.

Having briefly explained the general structure of the BSW’s
frame which is directly responsible for generating power, it is crucial to
explain an important feature of the frame of the BSW that has an enormous and
direct impact on how much power it generates; a hasty use of the aforementioned
power output formula will give us a low,

**figure. On the other hand, taking into consideration the unique structure of the BSW’s frame and how the columns are arranged in series, the same BSW will yield much higher power output figure or the***Conservative Power Output***.***Actual Power Output*
By applying the same method we previously
applied on example A, here is a summary of all the critical information needed
to reach the two sets of power output figures, a low

**figure and a high***conservative***figure representing the total power generated by all columns combined:***actual*
1. A BSW with

**30m x 30m**frame has 15 columns lettered A, B, C, D, E. F, G, H, I, J, k, L, M, N, and O.
2. Each column is 2m wide and 30m long

3. Starting from the far end of the
frame and moving toward the Central Post of the BSW, column A is the farthest
from the Central Pole and O is the closest; the radius values of the 15
columns, from column A to column O, are as follow: 60m, 58m, 56m, 54m, 52m, 50m,
48m, 46m, 44m, 42m, 40m, 38m, 36m,
34m and 30m.

**Conservative Power output:**

In a conservative power output
calculation, the radius of the frame is 60m and its height 30m.

P = 0.5 x 1.23 x (2 x 30 x 60) x 10

^{3 = }**2214KW =****2.2MW****Actual Power Output:**

In an actual power output
calculation, we shall calculate the power output of each column, a total of 15
columns. And because each column produces different amount of power
corresponding directly to the value of its radius, we shall calculate all 15
power output values, add them together and reach the actual power produced by a
BSW with 30m x 30m frame:

Power produced by column A = 0.5 x 1.23 x (2 x 60 x 30) x 10

^{3}= 2250KW
Power produced by column B = 0.5 x
1.23 x (2 x 58 x 30) x 10

^{3}= 2175KW
Power produced by column C = 0.5 x
1.23 x (2 x 56 x 30) x 10

^{3}= 2100KW
Power produced by column D = 0.5 x
1.23 x (2 x 54 x 30) x 10

^{3}= 2025KW
Power produced by column E = 0.5 x
1.23 x (2 x 52 x 30) x 10

^{3}= 1950KW
Power produced by column F = 0.5 x 1.23 x (2 x 50 x 30 x 10

^{3}= 1875KW
Power produced by column G = 0.5 x
1.23 x (2 x 48 x 30) x 10

^{3}= 1800KW
Power produced by column H = 0.5 x
1.23 x (2 x 46 x 30) x 10

^{3}= 1725KW
Power produced by column I = 0.5 x
1.23 x (2 x 44 x 30) x 10

^{3}= 1650KW
Power produced by column J = 0.5 x
1.23 x (2 x 42 x 30) x 10

^{3}= 1575KW
Power produced by column K = 0.5 x 1.23 x (2 x 40 x 30) x 10

^{3}= 1500KW
Power produced by column L = 0.5 x
1.23 x (2 x 38 x 30) x 10

^{3}= 1425KW
Power produced by column M = 0.5 x
1.23 x (2 x 36 x 30) x 10

^{3}= 1296KW
Power produced by column N = 0.5 x
1.23 x (2 x 34 x 30) x 10

^{3}= 1275KW
Power produced by column O = 0.5 x
1.23 x (2 x 32 x 30) x 10

^{3}= 1200KW
Power produced by column P = 0.5 x 1.23 x (2 x 30 x 30 x 10

^{3}= 1125KW**Total Power = 26946KW**

**(26.9MW)**

**The****Blinking sail windmill**does not need a prototype to prove its magical capability since the sails which move boats and ships is the proto type for this invention.**This windmill has one of the sales blocking the wind all the time. Therefore it generates power. While all the other sails letting the wind to pass through freely without any obstruction, so as if they do not exist. The result is one sail like in the ship generating power capable of moving a big electrical generator or a big water pump.**

**The sail boats race which takes place every year where the boats travel around the world and all the power is supplied to these boats for this very long trip comes from a piece of cloth its price equivalent to some gallons of petrol. If changed to an engine boat it will need tons and tons of petrol to complete the journey around the world besides the spare parts and the initial high cost.**

**When you watch these boats you can really see them moving at a high speed and cutting through the water with real force and big power and all of this is coming from a peace of cloth practically worth's nothing.**

**If we make the electrical generator of the Blinking Sail Windmill having multi coil so when the wind is week only one coil activated then when the wind gets faster the second coil is activated so we get more electrical power and if the wind gets stronger the third coil activated and so on.**

**when the wind gets much stronger the spiral spring of the horizontal bars starts to act so the horizontal bars start to swing to the other side, so even the active sail ( the sail which is blocking the wind) starts to let some of the wind to pass through the active sail so the wind do not damage the sail and as the wind gets stronger the gap gets bigger, therefore all the time the Blinking Sail Windmill is safe and generates electricity at the strongest winds besides generating electricity at the weakest wind near to stand still speed.**

**Jasim Al-azzawi**

**Giant manufacturers have to scrap all their factories & make new once. Therefore they don’t**

**want this breakthrough Blinking sail windmill.**

**Plus it will cancel all their contracts for new wind farms which they have now they will lose billions**

**This new windmill can be made by any one it is so simple design. And can be assembled by any one with no cranes at all**

**It's rare to see that clearly how much concrete there's in an offshore wind turbine, this is just for 30MW**

**And it can be assembled in very short time by very unskilled people. see this vidio..**

**The video above shows step by step how it is made and assembled that is the 20x20 meter windmill**

**It can be assembled by any unskilled people it is so cheep so efficient so easy for maintenance.**

**The solution to energy problem of this planet is this breakthrough windmill**

**Which is 1000 times more efficient than present windmills in view of cost to the energy production**

**Where with this Blinking sail windmill if we build offshore huge windmills with a cost of one billion dollars**

**They will give us power equivalent to one trillion dollars windmills of the types used to day.**

**It may sound unbelievable but the calculations prove it without any doubt.**

**Send me an email I will send you the calculations which proves that.**

**No one can argue with calculations because math’s is a constant thing no one can proves it wrong no one at all.**

**US patent 7780416 blinking sail windmill fast wind**

**US****patent 7780416 blinking sail windmill gentle wind**

Blinking sail windmill

Patent Number:

**7780416**
Blinking sail windmill with safety control

Patent
Number: 8702393

Blinking
sail windmill, BSW

The rotational
surface area for a BSW which has frames 20 meters by 20 meters is:

40m x 20m =
800 square meters

Since only
one frame is active therefore:

We have %50
of the surface area is generation power which is:

800 x %50 = 400
square meters.

.

Three blades
windmill

The blade length is 20 meters therefore it
rotates in a circle its radius is 20 meters.

Surface area
for this windmill is:

2Πr

^{2}
2 x 3.141 x
20 x 20 = 2513 square meters

The blade
width is one meter therefore its surface area is:

1 x 20 = 20 square
meters

We have
three blades therefore their total surface area which is responsible for
generating the power is:

20 x 3 = 60 square
meters

So the Three
blades windmill has surface area of 2513
square meters of which only 60 square meters are active.

Therefore
the efficiency of this windmill in surface area wise is:

60/2513 x
100 = %2.388

.

If the blade
is 2 meters wide the three blades surface area will be:

2 x 60 = 120

Therefore
the efficiency of this windmill in surface area wise will be:

120/2513 x
100 = %4.78

Conclusion

The blinking
sail windmill efficiency in surface area wise is %50.

The Three
blades windmill efficiency in surface
area wise is %2.388

Therefore if
we divide the efficiency of the blinking sail windmill by the efficiency of the
Three blades windmill :

%50 / %2.388
= 20.9

Therefore
the blinking sail windmill is more efficient than the Three blades
windmill in active surface area wise by
20.9 times.

If the Three
blades windmill has blades 2 meters wide
then:

The blinking
sail windmill is more efficient than the Three blades windmill in active
surface area wise by %50 / %4.78= 10.5
times.

If we take cost and efficiency
in consideration then the 20 x 20 meters

**Blinking sail windmill**is more efficient than the 170 meter three blades windmill
The blade
length is 170 meters therefore it rotates in a circle its radius is 170 meters.

Surface area
for this windmill is:

2Πr

^{2}
2 x 3.141 x 170
x 170 = 181549.8 square meters

The blade
width is one meter therefore its surface area is:

1 x 20 = 170
square meters

We have
three blades therefore their total surface area which is responsible for
generating the power is:

170 x 3 = 510
square meters

So the Three
blades windmill has surface area of 181549.8
square meters of which only 510 square meters are active.

Therefore
the efficiency of this windmill in surface area wise is:

510 /181549.8
x 100 = %0.281

The blinking
sail windmill efficiency in surface area wise is %50.

The Three
blades windmill efficiency in surface
area wise is %0.281

Therefore if
we divide the efficiency of the blinking sail windmill by the efficiency of the
Three blades windmill :

%50 / %0.281=
177.93

Therefore
the blinking sail windmill is more efficient than the three blades windmill in
active surface area wise by 177.93 times per cost/ power generated.

Industrial design windmill for Wind farms very
low cost easy to assemble by unskilled workers.

http://www.youtube.com/watch?v=2vvbmGa0XVY&feature=youtu.be
Industrial-size Blinking Sail Windmill can
easily be manufactured, packed, transported and quickly assembled at site by
unskilled people in a very short period of time.

This video step by step shall outline the
manufacturing process of the Frame Unit, one of the key components of the
Blinking Sail Windmill.

Which consists from very simple parts which can
be made by any small factory in any country, even the poorest country in the
world.

These parts are perforated steel flat bars,
steel Angle, Mounted Bearings,

Swinging Window, Sail, Sail Shaft, very small Spiral
Springs, Vertical Post.

The Sail can be made of two thin layers of plastic
or synthetic materials,

ratenge,
sandwiching a mesh of fine steel wires, such as piano wires. The result
is a tough, yet light sail that can easily be moved by a light breeze

The Vertical Post made in 0ne or two meters
parts then assembled on site. Where each of these parts is made to be assembled
on site therefore it is easily manufactured, packed, transported and quickly
assembled at site.

**“BSW Power Output Calculations”**

The detailed calculations below will
shed ample light on the most crucial question concerning the BSW; how much
power the BSW will generate.

Using the universally accepted and
used formula to calculate power output by wind turbines:

Power output (P) = 0.5 x air density at sea level (1.23) x swept area x wind
velocity cubed.

P = 0.5 × 1.23 × 2RH × V

^{3 }where:
P = Power output

0.5= The efficiency rating assigned
to the majority of wind turbines

R= In a classic wind turbine, with three
horizontally spinning rotors, R is the radius of the spinning rotor

In the case of the BSW, however, R
is the radius of the active frame denoting the distance between the frame’s
vertical column and the BSW’s Central Post.

H: In a classic wind turbine, with
three horizontally spinning rotors, H is the

**of the spinning rotor***length*
In the case of the BSW, however, H
is the height of the vertical column of the active frame.

V

^{3 }= Wind velocity (cubed) in meters per seconds.
But before I outline the power
output calculations in some detail, and in order to understand and appreciate
how these calculations are achieved, it is absolutely critical to highlight an
important feature of the structure of the BSW’s frame which plays an important
role how power is generated and calculated:

“A BSW may have 2 frames (or 3 or 4 or more)
designed to spin and block the wind to generate electricity. Think of the BSW
frame as an Excel sheet consisting of multiple

**The columns will be juxta positioned next to each other; a series of columns, as if they are stitched together. BSWs of different sizes will have different number of columns. The larger the BSW the larger number of columns.***columns.*
The frame of a 10m x10m BSW has 5 columns, each
10m long; a frame of a 20m x 20m has 10 columns, each 20m long, while a 30m x
40m frame will have 20 columns, each 30m long.

Just like an Excel Sheet with multiple cells,
each column has multiple number of component units called Double Sided Units. A
Double Sided Units (DSU) is 2m wide and 1m long. Different size BSWs will have
different number of DSUs. For example, a BSW with 10m x 10m frame will have 200
DSU; a 20m x 20m frame will have 800 DSU while a 30m x 40m will have 2400 DSU”.

Having briefly explained the general structure of the BSW’s frame
which is directly responsible for generating power, it is crucial to explain an
important feature of the frame of the BSW that has an enormous and direct
impact on how much power it generates; a hasty use of the aforementioned power
output formula will give us a low,

**figure. On the other hand, taking into consideration the unique structure of the BSW’s frame and how the columns are arranged in series, the same BSW will yield much higher power output figure or the***Conservative Power Output***. For example, we can show that:***Actual Power Output*
(i)
A BSW
with 10m x 10m frame can generate 123KW or 367KW

(ii)
A BSW
with 20m x 20m frame can generate 492KW or 2.6 MW

(iii)
A BSW
with 30m x 40m frame can generate 1476kw or 10MW.

But how can we explain this huge discrepancy in
power output by the same BSW?

As you can notice that the power discrepancy in
a BSW with 10m x 10m frame is huge; (123KW and 367KW). In using the power
output formula to calculate the lower figure (123KW) we simply aggregate the
power produced by all five columns i.e. we do not consider each column
separately nor do we assign a unique and corresponding radius (R) to each
individual column. Instead we simply use one general figure as a radius for all
columns and apply it to the entire frame despite the obvious fact that each
column has a unique and different radius of its own and produces its own
specific amount of power which is directly corresponding to its unique radius.

In the 2RH section of the power output
calculation formula quoted above we simply use 10m to denote the radius (R) of
the entire frame, although each of the five columns has different radius of its
own which is its distance from the Central Post of the BSW.

In light of the above explanation, now I would
like to show you how we can get two sets of different power output figures to
reflect the above-mentioned observation.

To drive the above point home and make it
absolutely crystal clear I shall use three examples to show you how we can get
a low

**figure and an***conservative***high power output figure for the same BSW.***actual***A: So, let us begin with a BSW with 10m x 10m frame.**

*Our calculations can show that this BSW can generate either 123KW or 367KW. But how?*
This frame has 5 columns, each column is 2m wide
and 10m long.

Despite the fact that the frame has 5 columns we
shall assume that all 5 columns will have the same radius of 10m and they will collectively
generate only 123KW. We can simplify the matter even further by assigning
letters to the 5 columns, A, B, C, D and E. All five lettered columns will have
the same radius value of 10m.In the

**method we do not calculate the power generated separately by each individual column. Instead the frame will be considered as one integral frame with 10m radius and 10m height. Thus:***conservative***Conservative Power Output**

P = 0.5 x 1.23 x 2RH x V

^{3}
P = 0.5 x 1.23 x (2 x 10 x 10) x 10

^{3 =}**123KW**
Now, let us calculate the

**actual**power generated by the same BSW with 5 columns. The power output figure will be a lot higher. And the reason is that each of the 5 columns, A, B, C, D and E generate its own unique amount of power corresponding directly to the value of its radius.
Putting in a nutshell as a general theory:

*“All factors (values) of all 5 columns being equal, the value of their radius will determine the amount of energy they produce; the bigger the radius the larger the power output”*
So how do
we do that?

Let us remember that each of the 5 lettered
columns has its own specific radius, reflecting its corresponding distance from
the Central Post of the BSW.

Remember the Columns are positioned in series.

So, starting from the far end of the frame and
moving towards the Central Post: Column A is 10m away from the central Post of
the BSW i.e. its radius is 10m

Column B is 8m away from the Central Post of the
BSW i.e. its radius is 8m

Column C is 6m away from the Central Post of the
BSW i.e. its radius is 6m

Column D is 4m away from the Central Post of the
BSW i.e. its radius is 4m

Column E is 2m away from the Central Post of the
BSW i.e. its radius is 2m

Now we are in a position to calculate the power generated
by each column, depending on its corresponding radius.

**Actual Power Output**

Power produced by column A = 0.5 x 1.23 x (2 x 10 x 10 x 10

^{3}= 123 KW
Power produced by column B = 0.5 x 1.23
x (2 x 8 x 10) x 10

^{3}= 98 KW
Power produced by column C = 0.5 x
1.23 x (2 x 6 x 10) x 10

^{3}= 73 KW
Power produced by column D = 0.5 x
1.23 x (2 x 4 x 10) x 10

^{3}= 49 KW
Power produced by column E = 0.5 x
1.23 x (2 x 2 x 10) x 10

^{3}= 24 KW
Total power output =

**367kw**
By adding all the power generated by
all 5 columns the

**(total) power generated by the same BSW is***actual***3,67KW**, three times the value of the**figure of 123KW***conservative***B: In our second example we shall consider a BSW with 20m x 20m frame.**

*The calculations below will show that this BSW can generate as conservative power 492KW (almost 0.5 MW) or as actual power 2,675KW (more than 2.6MW).*
By applying the same method we previously
applied on example A, here is a summary of all the critical information needed
to reach the two sets of power output figures, a low

**figure and a high***conservative***figure representing the total power generated by all columns combined:***actual*
1. A BSW with 20m x 20m frame has 10
columns lettered A, B, C, D, E. F, G, H, I and J.

2. Each column is 2m wide and 20m long

3. Starting from the far end of the
frame and moving toward the Central Post of the BSW, column A is the farthest
from the Central Pole and J is the closest; the radius values of the ten
columns, from column A to column J, are as follow: 20m, 18m, 16m, 14m, 12m,
10m, 8m, 6m, 4m and 2m.

**Conservative Power output:**

In a conservative power output
calculation, the radius of the frame is 20m and its height 20m.

P = 0.5 x 1.23 x (2 x 20 x 20) x 10

^{3 = }**492KW****Actual Power Output:**

In an actual power output
calculation, we shall calculate the power output of each column, a total of 10
columns. And because each column produces different amount of power
corresponding directly to the value of its radius, we shall calculate all ten
power output values, add them together and reach the actual power produced by a
BSW with 20m x 20m frame:

Power produced by column A = 0.5 x 1.23 x (2 x 20 x 20) x 10

^{3}= 492KW
Power produced by column B = 0.5 x
1.23 x (2 x 18 x 20) x 10

^{3}= 442.8KW
Power produced by column C = 0.5 x
1.23 x (2 x 16 x 20) x 10

^{3}= 393.6KW
Power produced by column D = 0.5 x
1.23 x (2 x 14 x 20) x 10

^{3}= 344.4KW
Power produced by column E = 0.5 x
1.23 x (2 x 12 x 20) x 10

^{3}= 295.2KW
Power produced by column F = 0.5 x 1.23 x (2 x 10 x 20 x 10

^{3}= 246KW
Power produced by column G = 0.5 x
1.23 x (2 x 8 x 20) x 10

^{3}= 196.8 KW
Power produced by column H = 0.5 x
1.23 x (2 x 6 x 20) x 10

^{3}= 147.6KW
Power produced by column I = 0.5 x
1.23 x (2 x 4 x 20) x 10

^{3}= 98.4 KW
Power produced by column J = 0.5 x
1.23 x (2 x 2 x 20) x 10

^{3}= 49.2 KW**Total Power=2675.2KW (2.67MW)**

**C: In our third example we shall consider a BSW with 30m x 40m frame.**

*Our calculations will show that as conservative this BSW can generate***1476**

*KW (1.476MW) or as an actual calculation will generate 10,326KW (more than 10MW).*
By applying the same method which we’ve
applied in the previous two examples, here is a summary of all the critical
information needed to reach the two sets of power output figures, a low

**figure and a high***conservative***figure representing the total power generated by all the columns combined:***actual*
4. A BSW with 30m x 40m frame has 20
columns lettered A, B, C, D, E. F, G, H, I, J, K, L, M, N, O, P, Q, R, S and T.

5. Each column is 2m wide and 20m long

6. Starting from the far end of the
frame and moving toward the Central Post of the BSW, column A is the farthest
from the Central Post and J is the closest; the radius values of the columns
from column A to column T are as follow: 40m, 38m, 36m, 34m, 32m, 30m, 28m,
26m, 24m, 22m, 20m, 18m, 16m, 14m, 12m, 10m, 8m, 6m, 4m and 2m.

**Conservative Power output:**

In a

**conservative**power output calculation, the radius of the frame is 40m and height 30m.
P = 0.5 x 1.23 x (2 x 40 x 30) x10

^{3 = }**1,476KW****Actual Power Output:**

In an

**actual**power output calculation, however, we shall calculate the power output of each column, a total of 20 columns. And because each column generates different amount of power corresponding directly to the value of its radius, we shall calculate all 20 power output values, add them up and reach the**actual**power produced by a BSW with 30m x 40m frame:
Power produced by column A = 0.5 x 1.23 x (2 x 40 x 30) x 10

^{3}= 1476KW
Power produced by column B = 0.5 x
1.23 x (2 x 38 x 30) x 10

^{3}= 1402KW
Power produced by column C = 0.5 x
1.23 x (2 x 36 x 30) x 10

^{3}= 1328KW
Power produced by column D = 0.5 x
1.23 x (2 x 34 x 30) x 10

^{3}= 1254KW
Power produced by column E = 0.5 x
1.23 x (2 x 32 x 30) x 10

^{3}= 1180KW
Power produced by column F = 0.5 x 1.23 x (2 x 30 x 30 x 10

^{3}= 1107KW
Power produced by column G = 0.5 x
1.23 x (2 x 28 x 30) x 10

^{3}= 1033KW
Power produced by column H = 0.5 x
1.23 x (2 x 26 x 30) x 10

^{3}= 959KW
Power produced by column I = 0.5 x
1.23 x (2 x 24 x 30) x 10

^{3}= 885KW
Power produced by column J = 0.5 x
1.23 x (2 x 22 x 30) x 10

^{3}= 811KW
Power produced by column K = 0.5 x 1.23 x (2 x 20 x 30) x 10

^{3}= 738KW
Power produced by column L = 0.5 x
1.23 x (2 x 18 x 30) x 10

^{3}= 664KW
Power produced by column M = 0.5 x
1.23 x (2 x 16 x 30) x 10

^{3}= 590KW
Power produced by column N = 0.5 x
1.23 x (2 x 14 x 30) x 10

^{3}= 516KW
Power produced by column O = 0.5 x
1.23 x (2 x 12 x 30) x 10

^{3}= 442KW
Power produced by column P = 0.5 x 1.23 x (2 x 10 x 30 x 10

^{3}= 369KW
Power produced by column Q = 0.5 x
1.23 x (2 x 8 x 30) x 10

^{3}= 295KW
Power produced by column R = 0.5 x
1.23 x (2 x 6 x 30) x 10

^{3}=221KW
Power produced by column S= 0.5 x
1.23 x (2 x 4 x 30) x 10

^{3}= 147KW
Power produced by column T = 0.5 x
1.23 x (2 x 2 x 30) x 10

^{3}= 73KW**Total Power = 10,326KW (10.326MW)**

**Sail windmill tower design**

**Sail windmill helical design**

## ليست هناك تعليقات:

## إرسال تعليق
